整機操作重量

Overall Operating Weight

6600KG

運輸尺寸Transport Dimension

長×寬×高mm L*W*H

7800×2200×3000

最小離地間隙

Min. Ground Clearance

350mm

裝載斗容 Bucket Capacity

1.5m3(2200mm寬width)

掘起力Breakout Force

38KN

裝載舉升能力

Loading Lifting Capacity

2800KG

鏟斗卸載高度

Bucket Dumping Height

3600mm

鏟斗卸載距離

Bucket Dumping Distance

1062mm

反鏟斗容

Backhoe Capacity（Width）

0.3m3(620mm寬width)

最大挖掘深度

Max. Digging Depth

4000mm

Optional Digging Depth可選挖深

5000mm-5500mm（挖臂帶伸縮）

挖斗回轉角

Swing Angle of backhoe

190o

最大牽引力

Max. Pulling Force

39KN

Wheel base軸距

1600mm

Wheel tread輪距

2680mm

發動機Engine

品牌/型號Brand/Model

YUNNEI YN48GBZ Turbo engine渦輪增壓發動機

型式Type

單列、直噴、四沖程、水冷

In Line，Direct injection，F(xiàn)our-Stroke，Water Cooling

額定功率Rated Power

92KW

可選發動機Optional Engine

YUCHAI/YCD4J22T-115（85KW））

YUCHAI/YCD4T33T6-115(國三90KW）

CUMMINS 74KW 4BT3.9-C100

CUMMINS EURO3 75KW QSB3.9-C100

EURO5 YUCHAI or EPA4 CUMMINS

轉向系統Steering System

轉向角Steering Angle

±36 o

系統壓力

Pressure of the system

12Mpa

驅動橋Axle

型號Model

大輪邊橋Big Wheel Hub Reducer

輪邊減速型式Final Reducer

一級輪邊減速Single Stage Final Reducer

傳動系統Transmission System

變矩器Torque Converter

型號Model

280

型式Type

單級、單相三元件Single-stage Three Elements

冷卻方式Cooling Method

油冷壓力循環Oil-cooling Pressure Circulation

變速箱Gearbox

型式Type

定軸式動力換檔Fixed Shaft Power Transmission

檔位數Optional Gears

前進4檔，后退4檔Four Gears Ahead, Four Gears Astern

最高車速Max.Speed

38Km/h

輪胎Tyre

規格Model

16/70-24

前輪氣壓

Pressure of Front wheel

0.22 Mpa

后輪氣壓

Pressure of Back Wheel

0.22 Mpa

制動系統Brake System

行車制動Service Brake

氣頂油鉗盤制動Air Over Oil Caliper Brake

外置式External Type

自調節Self-regulation

自平衡Self-balance

駐車/緊急制動

Emergency Brake

操縱力實施制動Operation Power Implementing brake

手操縱力解除制動Manual Operation Power Terminating Brake

液壓系統Hydraulic System

液壓系統壓力

Pressure of Hydraulic System

22Mpa
