整機操作重量Overall Operating Weight

6000KG

運輸尺寸Transport Dimension

長×寬×高 L*W*H

7600×2100×2900mm

軸距 Wheel base

2250mm

最小離地間隙 Min. Ground Clearance

300mm

裝載斗容 Bucket Capacity

1.3m3

掘起力Breakout Force

38KN

裝載舉升能力Loading Lifting Capacity

2500KG

鏟斗卸載高度Bucket Dumping Height

3500mm

后挖斗容Backhoe Capacity

0.3m3

最大挖掘深度Max. Digging Depth

4000mm

可選最大挖掘深度Optional Max. Digging Depth

5000mm-5500mm（挖臂伸縮Digging boom telescopic）

挖斗回轉角Swing Angle of backhoe

170o

最大牽引力Max. Pulling Force

39KN

輪距Wheel tread

2470mm

軸距Wheel base

1600mm

發動機Engine

型號Model

YUNNEI YN38GBZ Turbo Engine

型式Type

單列、直噴、四沖程、水冷

In Line，Direct injection，F(xiàn)our-Stroke，Water Cooling

額定功率Rated Power

76KW

可選發動機Optional engine

歐五4G33TC-75L常柴55.2KW

EPA4/歐五科勒KDI2504TCR發動機55KW

EPA4康明斯55KW發動機QSF2.8     EPA4康明斯QSF3.8

75KW康明斯4BT3.9-C100   玉柴YCF36100-S500歐五74KW

轉向系統Steering System

轉向角Steering Angle

±40 o

最小轉彎半徑Min. turning radius

4600mm

系統壓力Pressure of the system

12Mpa

驅動橋Axle

型式Type

四輪驅動Four wheel drive

輪邊減速型式Final Reducer

一級輪邊減速Single Stage Final Reducer

傳動系統Transmission System

變矩器Torque Converter

型號Model

265

型式Type

單級、單相三元件Single-stage Three Elements

冷卻方式Cooling Method

油冷壓力循環Oil-cooling Pressure Circulation

變速箱Gearbox

型式Type

動力換檔Power Transmission

檔位數Optional Gears

前進4檔，后退4檔Four Gears Ahead, Four Gears Astern

最高車速M(fèi)ax. Speed

30Km/h

輪胎Tyre

規格Model

16/70-20

制動系統Brake System

行車制動Service Brake

氣頂油鉗盤制動Air Over Oil Caliper Brake

外置式External Type

自調節Self-regulation

自平衡Self-balance

駐車/緊急制動Emergency Brake

操縱力實施制動Operation Power Implementing brake

手操縱力解除制動Manual Operation Power Terminating Brake

液壓系統Hydraulic System

液壓系統壓力Pressure of Hydraulic System

22Mpa
