整機基本參數Basic parameters of the whole machine

整機重量Total weight

5700KG

運輸時總長shipping length

6246(mm)

運輸時總高

Total height during transportation

2800(mm)

運輸寬度

Transport width

2200(mm)

輪胎中心距離Tire center distance

2200(mm)

配重離地間隙

Counterweight ground clearance

1035(mm)

輪胎數量umber of tires

750-16

動臂長度Boom length

3200(mm)

斗桿長度Stick length

1800(mm)

工作范圍

Working Range

最大挖掘高度Max.Digging Height

6550(mm)

最大卸載高度Max.Dumping Height

4200(mm)

最大挖掘深度Max.Digging Depth

3080(mm)

最大挖掘范圍Max.Digging radius

6590(mm)

推土鏟最大提升高度

Maximum lifting height of earth shovel

300(mm)

推土鏟最大掘地深度

The maximum digging depth of dozer

100(mm)

動力系統Dynamical system

發動機型號Model

新柴

額定功率power

36.8KW

冷卻方式Cooling method

水冷渦輪增壓water-cooling Turbo

液壓系統Hydraulic System

額定工作壓力Operating Pressure

22mpa

液壓泵Main pump

齒輪泵SGP1A2XFZH9

日本島津

液壓閥

韓國進口Korea

形式Shape

負載敏感系統

Load Sensing System

性能參數performance parameter

鏟斗容量（SAE）Bucket Capacity

0.3m3

爬坡能力Climbing ability

30°

最大挖掘力Maximum digging force

8200N

行走速度Travel speed

35KM/h

回轉速度Unit swing speed

9-11r/min

液壓油容量Hydraulic oil capacity

110L

燃油箱容量Hydraulic tank capacity

90L

駐車制動Parking brake

斷氣剎Air break

行車制動service brake

氣剎Kill

穩定裝置Stabilizers

支腿/選裝Legs / optional
